Lastnosti na dlani
-
Measurement range
0.5 to 1 000 μg/l (ppb)
-
Process temperature
< 50 °C (122 °F)
-
Process pressure
max. 0.5 bar (7.25 psi)
-
Measuring method
TOC determination by UV digestion and measurement of the differential conductivity
Področje uporabe
Total organic carbon (TOC) content strongly influences the quality of ultrapure water. A high TOC concentration can cause damage of water purification systems or compromise the required water quality. The CA78 online TOC analyzer provides continuous, accurate TOC monitoring ensuring consistently high quality of the ultrapure water used in your production processes. You gain full control of your product yield and quality.
The CA78 TOC analyzer is perfectly suited to TOC monitoring of ultrapure water in the following industries:
Power & Energy
Semiconductor production
Bodycare
Disinfectant production
With the following process conditions:
Conductivity: 2 µS/cm (standard), 10 µS/cm (order option)
pH range: Neutral
Prednosti
Real-time overview of water quality:
The online TOC analyzer measures continuously with a fast response time (t90) of 50 seconds. This enables you to react immediately to potential water contamination and to protect your product effectively.CA78 uses proven UV oxidation and differential conductivity measurement which is the most-established method for reliable TOC trace analysis in ultrapure water.
The analyzer's maintenance-friendly design in combination with our worldwide service network offers you complete support for the measuring point, from commissioning throughout the entire lifespan of the device.
Perfect adaption to your process needs:
Select between the high-precision 2 µS/cm conductivity version and the robust version that tolerates 10 µS/cm. Reduce your investment costs by the optional 3 channel configuration.
Segment Extended
-
Vrhunski produkti
- Visoko funkcionalni in praktični
Tehnična odličnost
Preprostost
-
Standardni produkti
- Zanesljivi, robustni, nezahtevni za vzdrževanje
Tehnična odličnost
Preprostost
-
Specialni produkti
- Zasnovani za posebej zahtevne aplikacije
Tehnična odličnost
Preprostost
Spremenljivo
| FLEX izbira | Tehnična odličnost | Preprostost |
|---|---|---|
Segment Fundamental Zadostite svojim osnovnim merilnim potrebam |
Tehnična odličnost
|
Preprostost
|
Segment Lean Obvladajte ključne procese na preprost način |
Tehnična odličnost
|
Preprostost
|
Segment Extended Optimirajte procese z inovativnimi tehnologijami |
Tehnična odličnost
|
Preprostost
|
Segment Xpert Imejte pod nadzorom najzahtevnejše aplikacije |
Tehnična odličnost
|
Preprostost
Spremenljivo |
Loading alternative products
Zgodbe o uspehu
-
-
Tehnične informacije (TI)
TOC Analyzer CA78
Determination of total organic carbon (TOC) in the trace range
EN SL 01/07/202224/01/2022Jezik:
angleščina
Verzija:
01/07/2022
Velikost datoteke:
963.6 KB
Ime datoteke:
TI01622CEN_0222-00.pdf
-
-
-
Navodila za uporabo (BA)
Analizator TOC – CA78
Določanje skupnega organskega ogljika (TOC) v sledovih
EN SL 09/08/202224/01/2022Jezik:
slovenščina
Verzija:
09/08/2022
Velikost datoteke:
3.6 MB
Ime datoteke:
BA02219CSL_0222-00.pdf
-
-
-
Inovacija (IN)
Sicheres deionisiertes Wasser für Kraftwerke und Halbleiterproduktion
Zuverlässige Online-Überwachung niedriger TOC-Werte
mit dem Analysator CA78Jezik:
nemščina
Verzija:
02/05/2022
Velikost datoteke:
718 KB
Ime datoteke:
IN01239CDE_CA78-lowres.pdf
-
-
-
Inovacija (IN)
Safe deionized water in power plant and semiconductor production
Precise and reliable online monitoring of low-range TOC values
with the CA78 analyzerJezik:
angleščina
Verzija:
18/02/2022
Velikost datoteke:
616.8 KB
Ime datoteke:
IN01239CEN_CA78-lowres.pdf
-
-
-
Izjava EU
Product family: TOC Analyzer
Product root: CA78-, CA79-
Declaration number: EU_00978_01.21EN SL 02/12/2021Jezik:
angleščina
Verzija:
02/12/2021
Velikost datoteke:
265 KB
Ime datoteke:
EU_00978_01.21.pdf
-
-
-
Ocenjena skladnost za Združeno kraljestvo
Product family: TOC Analyzer
Product root: CA78-, CA79-
Declaration number: UK_00479_02.23EN SL 31/05/2023Jezik:
angleščina
Verzija:
31/05/2023
Velikost datoteke:
219 KB
Ime datoteke:
UK_00479_02.23_CA78_CA79.pdf
-
-
-
Razno
Product family: Liquiline, Liquiline M, Liquisys chlorine, Liquisys conductivity, Liquisys oxygen, Liquisys pH/ORP, New analyzer pla tform, SmarTec, SmarTec S, TOC Analyzer, TOCII
Product root: CA72TOC-, CA76NA-, CA78-, CA79-, CA80AL-, CA80AM-, CA80COD-, CA80CR-, CA80FE-, CA80HA-, CA80NO-, CA80PH-, CA80SI-, CA8
0TN-, CA80TP-, CCM223-, CCM253-, CLD132-, CLD134-, CLD18-, CLM223-, CLM223F-, CLM253-, CM14-, CM42-, CM442-, CM442R-, CM444-, CM444R
-, CM448-, CM448R-, CM44P-, CM72-, CM82-, COM223-, COM253-, CPM223-, CPM253-, CYM290-, CYM291-
Region: Eurasian Economic Union
Approval agency: EAC
Approval number: EAEC N RU D-DE.PA01.B.00347/21Jezik:
ruščina
Verzija:
11/10/2021
Velikost datoteke:
201.2 KB
Ime datoteke:
EAEC N RU D-DE.PA01.B.00347_21.pdf
-
-
-
Razno
Product family: Liquiline, Liquiline M, Liquisys chlorine, Liquisys conductivity, Liquisys oxygen, Liquisys pH/ORP, New analyzer pla tform, SmarTec, SmarTec S, TOC Analyzer, TOCII
Product root: CA72TOC-, CA76NA-, CA78-, CA80AL-, CA80AM-, CA80COD-, CA80CR-, CA80FE-, CA80HA-, CA80NO-, CA80PH-, CA80SI-, CA80TN-, C
A80TP-, CCM223-, CCM253-, CLD132-, CLD134-, CLD18-, CLM223-, CLM223F-, CLM253-, CM14-, CM42-, CM442-, CM442R-, CM444-, CM444R-, CM44
8-, CM448R-, CM44P-, CM72-, CM82-, COM223-, COM253-, CPM223-, CPM253-, CYM290-
Region: Eurasian Economic Union
Approval agency: EAC
Approval number: EAEC N RU D-DE.PA01.B.00339/21Jezik:
ruščina
Verzija:
11/10/2021
Velikost datoteke:
223.1 KB
Ime datoteke:
EAEC N RU D-DE.PA01.B.00339_21.pdf
-
