Lastnosti na dlani
-
Input
1 to 4x Memosens digital input
2x 0/4 to 20mA Input optional
2 to 4x Digital input optional -
Output / communication
2 to 8x 0/4 to 20 mA current outputs, alarmrelay,
4x relay, ProfibusDP, Modbus RS485, Modbus TCP, Ethernet -
Ingress protection
IP66 / IP 67
Področje uporabe
The Liquiline CM444 transmitter allows you to connect up to 4 Memosens sensors of your choice from over 12 measurement parameters. It offers automatic sensor recognition, flexible expandability, and standardized spare parts with all other devices of the Liquiline platform. With its inputs, outputs, controllers, and math modules, you can even control cleaning systems or dosing pumps. Heartbeat Technology helps you find the ideal balance between measuring point availability and maintenance costs.
Liquiline CM444 is suitable for all industries and their utilities, such as:
Food & Beverages
Life Sciences
Power & Energy
Water & Wastewater
Chemicals
Marine
It features the following communication protocols and interfaces:
0/4...20 mA
HART
PROFIBUS DP
Modbus RS485/RTU
Modbus TCP
EtherNet/IP
PROFINET
Webserver
The transmitter can be extended with a module whose explosion protection approvals, such as IECEx, ATEX, and CSA, allow the connection of sensors installed in hazardous areas.
Prednosti
Clever simplicity:
One controller for all parameters and applications, intuitive user interface, automatic sensor recognition, hot plug & play with pre-calibrated Memosens sensors.Highest flexibility:
Universal modules for all parameters minimize spare part stock and allow for easy 1-click extension to up to 8 channels at any time.Seamless system integration:
Unique portfolio of communication standards suits every distributed control system (DCS).Simple and safe commissioning:
Saving configuration on SD card enables fast set-up on duplicate installations.Process control from a distance:
Integrated web server that allows the operator to remotely view diagnostic data, perform configurations, or access device parameters in any web browser - even via Smartphone.Higher availability, lower costs:
Heartbeat Technology enables status-oriented maintenance and easy verification of the entire measuring point and helps to carry out optimization measures.
Videoposnetki
-
Standardni produkti
- Zanesljivi, robustni, nezahtevni za vzdrževanje
Tehnična odličnost
Preprostost
-
Specialni produkti
- Zasnovani za posebej zahtevne aplikacije
Tehnična odličnost
Preprostost
Spremenljivo
FLEX izbira | Tehnična odličnost | Preprostost |
---|---|---|
Segment Fundamental Zadostite svojim osnovnim merilnim potrebam |
Tehnična odličnost
|
Preprostost
|
Segment Lean Obvladajte ključne procese na preprost način |
Tehnična odličnost
|
Preprostost
|
Segment Extended Optimirajte procese z inovativnimi tehnologijami |
Tehnična odličnost
|
Preprostost
|
Segment Xpert Imejte pod nadzorom najzahtevnejše aplikacije |
Tehnična odličnost
|
Preprostost
Spremenljivo |
Segment Extended
-
Vrhunski produkti
- Visoko funkcionalni in praktični
Tehnična odličnost
Preprostost
Predhodnik
-
-
Glavni podatki naprave (GSD)
General Station Description (GSD) - Liquiline CM44x - PROFINET
Jezikovno neodvisno - 03/2021
Any, PROFINET System, Any
Jezik:
Jezikovno neodvisno
Verzija:
22/03/2021
Velikost datoteke:
23.2 KB
Ime datoteke:
EH_PN_AN_Liquiline_0x859C_0x01_GSD.zip
-
-
-
Navodila za uporabo (BA)
BA Liquiline CM442/CM444/CM448
Angleška različica - 09/2023
Universal four-wire multichannel controller Field device
EN SL 25/09/202310/08/202204/07/202208/10/202106/05/2021Jezik:
angleščina
Verzija:
25/09/2023
Velikost datoteke:
7.8 MB
Ime datoteke:
BA00444CEN_3123-00.pdf
-
-
-
Tehnične informacije (TI)
TI Liquiline CM442/CM444/CM448
Multiparameter transmitter with a maximum of eight measuring channels
based on digital Memosens technologyEN SL 28/08/202410/08/202204/07/202203/05/202211/05/2020Jezik:
angleščina
Verzija:
28/08/2024
Velikost datoteke:
5.9 MB
Ime datoteke:
TI00444CEN_2724-00.pdf
-
-
-
Navodila za uporabo (BA)
Memosens
Sensor inputs with Memosens protocol
EN SL 30/05/202228/02/2019Jezik:
angleščina
Verzija:
30/05/2022
Velikost datoteke:
3.3 MB
Ime datoteke:
BA01245CEN_0822-00.pdf
-
-
-
Navodila za uporabo (BA)
BA Liquiline CM442/CM444/CM448
Universal four-wire multichannel controller
Field deviceEN SL 25/09/202310/08/202204/07/202208/10/202106/05/2021Jezik:
angleščina
Verzija:
25/09/2023
Velikost datoteke:
7.8 MB
Ime datoteke:
BA00444CEN_3123-00.pdf
-
-
-
Navodila za uporabo (BA)
Operating Instructions
Communication via the HART protocol
EN SL 27/06/201315/09/2011Jezik:
angleščina
Verzija:
27/06/2013
Velikost datoteke:
1.9 MB
Ime datoteke:
BA00486CEN_0213.pdf
-
-
-
Kratka navodila (KA)
KA Liquiline CM442/CM444/CM448
Univerzalni 4-žični večkanalni krmilnik
EN SL 25/09/202312/08/202208/10/202106/05/202130/11/2019Jezik:
slovenščina
Verzija:
25/09/2023
Velikost datoteke:
3.1 MB
Ime datoteke:
KA01159CSL_1023-00.pdf
-
-
-
Navodila za vgradnjo (EA)
SD card kit
32 GB, industrial flash drive
EN SL 23/03/2021Jezik:
angleščina
Verzija:
23/03/2021
Velikost datoteke:
506.7 KB
Ime datoteke:
EA01354CEN_0121.pdf
-
-
-
Navodila za vgradnjo (EA)
Kit CM44x / CSXxx / CA80xx Kit Module 485/ETH Installation Instructions
For Ethernet configuration, PROFIBUS, Modbus
EN SL 22/08/201722/06/201531/01/201431/12/2011Jezik:
angleščina
Verzija:
22/08/2017
Velikost datoteke:
2.1 MB
Ime datoteke:
EA00009CA2_0417.pdf
-
-
-
Navodila za vgradnjo (EA)
Kit Mastbefestigung Post mounting kit 71096920 Installation Instructions
Kit Mastbefestigung
EN SL 28/02/201711/06/201431/12/2011Jezik:
angleščina
Verzija:
28/02/2017
Velikost datoteke:
659.1 KB
Ime datoteke:
EA00010CA2_0317.pdf
-
-
-
Navodila za vgradnjo (EA)
Einbauanleitung/ Installation Instructions Kit Module/Modules
Für erweiterte Funktionalität
For extended functionalityEN SL 07/07/201425/03/201331/12/2011Jezik:
angleščina
Verzija:
07/07/2014
Velikost datoteke:
2.4 MB
Ime datoteke:
EA00008CA2_0314.pdf
-
-
-
Navodila za vgradnjo (EA)
Kit CM44x/CSXxx/CA80XX
Module 485MB or 485DP
For Ethernet configuration,PROFIBUS DP, Modbus RS485EN SL 28/11/2022Jezik:
angleščina
Verzija:
28/11/2022
Velikost datoteke:
1.8 MB
Ime datoteke:
EA01447CEN_0122-00.pdf
-
